| Parameter | TTP-2410M 203dpi | TTP-2410M Pro 203dpi |
|---|---|---|
| Model | TTP-2410M 980250128-30LF | TTP-2410M Pro 980250128-50LF |
| Resolution | 203dpi (8 dots/mm, 0.125mm dot pitch) | 203dpi (Same as base model) |
| Compatible Printers | TTP-2410M (2020+), TTP-2410MA | TTP-2410M Pro, TTP-2410M ProH |
| Print Width | 104mm (4.09″) – Supports 110mm labels | 104mm (Same as base model) |
| Heating Elements | 832 pins (Ceramic + Nickel-Chromium) | 832 pins (Enhanced ceramic coating, +30% lifespan) |
| Life Expectancy (TT/DT) | 30km / 40km – 1-year warranty | 40km / 50km – 2-year industrial warranty |
| Interface | 30-pin FPC (Locking clip) | 30-pin FPC + GPIO (Industrial I/O) |
| Temperature Range | -10°C to 50°C (printing) | -15°C to 55°C (extended industrial) |
| Material | Plastic + metal-reinforced bracket | Full-metal bracket (IP54 dustproof, corrosion-resistant) |
| Weight | 140g | 165g (Reinforced structure) |
Pro Model Upgrades
Durability:
Full-metal bracket with corrosion coating (ISO 13485 medical-certified).
Enhanced ceramic coating: 30% better scratch resistance (100km cleaning cycle vs. 80km base).
Functionality:
Built-in GPIO for sensors/cutters (e.g., TSC FC-200 full cutter).
“Industrial Mode”: 8-hour continuous printing without overheating.
Certifications:
ATEX (explosive environments) and FDA (food-contact compliance).
Compatibility Matrix
| Printer Model | Compatible Printhead | Firmware Requirement | Typical Applications |
|---|---|---|---|
| TTP-2410M (Base) | TTP-2410M 980250128-30LF | ≥V2.6 | Warehouse labels, logistics waybills |
| TTP-2410M Pro | TTP-2410M Pro 980250128-50LF | ≥V3.1 (Industrial Mode) | Chemical drums, medical traceability (ISO 13485) |
| TTP-2410MA (Android) | Base model (interchangeable) | Android auto-adaptive | Mobile printing (with TSC Android SDK) |
| TTP-2410M ProH (High-Temp) | Pro head (with optional fan) | ≥V3.3 | High-temperature workshops (40°C+ operation) |
