| Parameter | Specification |
|---|---|
| Compatible Printer | A4.3 Plus 300DPI Thermal Transfer/Direct Thermal Label Printer |
| Print Technology | Thermal Transfer (ribbon required) or Direct Thermal (ribbonless) |
| Resolution | 300 dpi (12 dots/mm) – High precision for barcodes, graphics, and small text |
| Print Width | 104 mm (4.09 inches) or printer-specific (verify model requirements) |
| Printhead Type | Flat Ceramic Thermal Printhead |
| Heating Elements | 1,248 dots (300 dpi × 4.09 inches) |
| Voltage | 24V DC (typical for industrial thermal printers) |
| Lifespan | ~50,000–100,000 meters (depends on media, ribbon type, and maintenance) |
| Media Compatibility | Thermal paper, synthetic labels (PET, PVC), tags, wristbands |
| Ribbon Compatibility | Wax, wax-resin, or resin-based ribbons (for thermal transfer mode) |
| Operating Temperature | 5°C to 40°C (41°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity Range | 20% to 85% non-condensing |
| Cleaning Requirements | Use lint-free swabs and 90%+ isopropyl alcohol (avoid abrasive materials) |
| Installation Notes | Handle with care; avoid touching heating elements. Follow ESD precautions. |
Sold out
5977383 Thermal Printhead A4.3 Plus 300DPI
CAB THERMAL PRINTER HEAD
COMPATIBILITY:for CAB A4.3+ Series Printer
RESOLUTION:300dpi
Part Number:5977383
₹9,999.00
Out of stock
